General Purpose Relay, 12V DC Coil Volts, 3PDT

General Purpose Relay, 12V DC Coil Volts, 3PDT

  • Schneider
  • General Purpose Relay, Base Shape Octal, Coil Voltage 240V AC, Contact Form 3PDT, Current Rating 10 A, Electrical Connection 11-Pin Terminal, Flat Pin Width Not Applicable, Number of Pins 11, Pin Shape Round, Sealing Enclosed, Status Indicator Mechanical Flag, Contact Rating (AC) 10 A @ 300V, Contact Rating (DC) 5 A @ 30V, Horsepower @ 120V AC 1/3 hp, Horsepower @ 240V AC Not Rated, Mounting Style Socket, Push-To-Test Method No Button, Body Depth 2.1 in, Body Height 2.66 in, Body Width 1.4 in

    graingerSKU: 335HV2, mscSKU: , zoro_no: G1381568, mongo_id: 65bbe88a9a749db822798ed5

Web Price
$76.94 / each
Qty

Product Details

-40 to 131°F (-40 to 55°C)
Octal
2.1 in
1.4 in
2.66 in
2.66 in
1.4 in
1.4 in
3 A 120 V AC inductive control circuit UL 508; 1.5 A 240 V AC inductive control circuit UL 508; 10 A 277 V AC resistive control circuit UL 508; 10 A 30 V DC resistive control circuit UL 508
240V AC
AC
12V DC
8501NR61, 8501NR62
8501NR61, 8501NR62
8501NR61, 8501NR62
8501NR61, 8501NR62
3PDT
3PDT
Silver Alloy
10 A @ 300V
5 A @ 30V
240 V AC
China
10 A
1.4 in (35.56 mm)
11-Pin Terminal
Pin
Enclosed
Not Applicable
8501NR62; 8501NR61
2.66 in (67.56 mm)
1/3 hp
Not Rated
1 hp 277 V AC; 0.33 hp 120 V AC
5/16 hp
Not Rated
Without test button
131 Degrees F
300V AC, 30V DC
-40 Degrees F
Yes
Socket
Socket
11
-40-131°F
20 ms - pick-up || 20 ms - drop-out
2.7 in
2.66 in
1
No indicator
Round
3 VA
3 VA
UL Listed; UL Recognized; CSA; CE
Relay
No Test Button
No Button
Socket
General purpose
20 msec
Enclosed
Square D 8501K Series
Tubular
B
Socket / Octal / 11
CE Certified, CSA Certified, UL Listed
Mechanical Flag
300 V AC; 30 V DC
1.4 in (35.56 mm)
