Home / Digital Monitoring Relay Speed Monitorin

Digital Monitoring Relay Speed Monitorin

SKU
Brand Siemens
Categories
Description Speed Monitoring Relay, Delay Time 1 to 900 sec, Delay Type Adjustable, Electrical Connection Screw Terminal, IP Rating IP20, Input Voltage 24 to 240V AC/DC, Mounting Style DIN Rail, Number of Pins 12, Standards CCC, CE Certified, EAC, RCM, UL Listed, Body Depth 4.02 in, Body Height 3.39 in, Body Width 0.89 in, Electrical Operating Durability 100,000
graingerSKU: , mscSKU: , zoro_no: G8681516, mongo_id: 65bbe9b522d7a989a996fa6a

Web Price

$514.99 / each

Qty

Product Details

Body Depth 4.02 in

Body Depth - Relay 4.02 in

Body Height - Relay 3.39 in

Body Width - Relay 0.89 in

Country of Origin (subject to change) Czechia

Delay Time 1 to 900 sec

Delay Type Adjustable

Depth 102 millimetre

Electrical Connection - Relay Screw Terminal

Environmental Protection IP20

Features 1 change-over contact, Hysteresis 0.1 to 99 rpm, ON delay, 1 to 900 s, and Tripping delay, 0.1 to 99.9 s, Overshoot and Undershoot 24 to 240 V AC/DC at 50 to 60 Hz, DC and AC, Speed monitoring from 0.1 to 2200 rpm

Frequency 50/60 Hz

function rotating speed monitoring present Yes

Height 86 millimetre

Input or Control Voltage 24 to 240 V AC/DC

Input Voltage 24 to 240V AC/DC

IP Rating IP20

Item - Relay Safety Monitoring Relay

Maximum Operating Temperature 140 Degrees F

Mechanical Operating Durability 10,000,000

Minimum Operating Temperature -13 Degrees F

Mounting Style DIN Rail

Number of outputs, safety related, delayed, semi-conductor 0
