Wet DP Sensor, 0-100 PSID, 4-20mA

SKU
Brand Siemens
Categories
Description Differential Pressure Sensor, For Media Air and Water, Accuracy +/-0.50 Percent, Power Required 7.5 to 33V DC, Power Source 7.5 to 33V DC, Output 4 to 20mA, Sensing Element Type Ceramic, Maximum Differential Pressure Measurement 100 in wc, Maximum Operating Temperature 185 Degrees F, Minimum Operating Temperature 5 Degrees F, Mounting Hole Center to Center Distance 1 3/4 in, Product Type Differential Pressure Sensor, Overall Height 3 in, Process Connection Gender Female
graingerSKU: null, mscSKU: null, zoro_no: G6053113, mongo_id: 65bbe6283aaddbd5a900fa48

Web Price

$673.74 / each

Product Details

Accuracy +/-0.50%

Application General HVAC

Country of Origin (subject to change) Switzerland

For Media Air and Water

Housing Material Stainless Steel

Hysteresis +/-0.5%

IP Rating IP65

Manufacturers Warranty Length 5 yr

Maximum Differential Pressure Measurement 100 in wc

Maximum Operating Temperature 185 Degrees F

Minimum Operating Temperature 5 Degrees F

Mounting Hole Center to Center Distance 1 3/4 in

Mounting Hole Diameter 1 in

NEMA Rating 4

Output 4 to 20mA

Overall Height 3 in

Overall Width 5 in

Package Quantity 1

Power Required 7.5 to 33V DC

Power Source 7.5 to 33V DC

Process Connection Gender Female

Process Connection Size 1/4 in

Process Connection Type NPT

Product Type Differential Pressure Sensor

Repeatability Less Than+/-0.5%

Response Time 5 msec

Sensing Element Type Ceramic

Series QBE

Standards CE Listed, EMC 2004/108/EC Directive, EN 61 000-6-2, EN 61326-1, EN 61 000-6-3, EN 61326-1, EN 61326-2-3, ISO 14001, ISO 9001, RoHS RL 2002/95/EG, SN 36350

Wetted Materials 303 Stainless Steel
