Home / Cable Pull Switch, 20A, Right, 1NO+1NC
Cable Pull Switch, 20A, Right, 1NO+1NC

Cable Pull Switch, 20A, Right, 1NO+1NC

  • Square D
  • Emergency Cable Pull Switch, Switch Function Maintained, Mounting Style Single End, AC Contact Rating 12.5A @ 240 V AC, 20A @ 120 V AC, 5A @ 600 V AC, 6.25A @ 480 V AC, Contact Form 1NC/1NO, Not Applicable Reset, Operating Force Not Applicable, NEMA Rating 1, 12, 13, 2, 4, Indicator None, Cable Connection Location Right, Thermal Amperage 20 A, Length 4.95 in, Width 2.31 in, Depth 2.1 in, Switching Ability Single Cable, DC Contact Rating 0.2A @ 600 V DC, 1A @ 250 V DC, 5A @ 120 V DC

    graingerSKU: 2FM01, mscSKU: , zoro_no: G3163675, mongo_id: 65bbe80e22d7a989a98d33f1

Web Price
$398.74 / each
Qty

Product Details

12.5A @ 240 V AC, 20A @ 120 V AC, 5A @ 600 V AC, 6.25A @ 480 V AC
-20-120°F
-20-120°F
style 2
cast aluminium
fixed
Right
1 entry for 1/2 - 14 NPT ANSI B1.20.1
Cast Aluminum
A600, AC (Ue = 600 V) Ie = 5 A NEMA rating designation || A600, AC (Ue = 480 V) Ie = 6.25 A NEMA rating designation || A600, AC (Ue = 240 V) Ie = 12.5 A NEMA rating designation || A600, AC (Ue = 120 V) Ie = 20 A NEMA rating designation || P600, DC (Ue = 600 V) Ie = 0.2 A NEMA rating designation || P600, DC (Ue = 250 V) Ie = 1 A NEMA rating designation || P600, DC (Ue = 120 V) Ie = 5 A NEMA rating designation
1NC/1NO
snap action
90/10 AgCdO on copper backing stationary contact || silver on steel backing moveable contact
A
1 NC + 1 NO
Mexico
0.2A @ 600 V DC, 1A @ 250 V DC, 5A @ 120 V DC
2.1 in
L140
screw-clamp terminals AWG 22 to AWG 12
class 0 IEC 61140
by the body
Preventa XPS Safety Relays
rotary head
4.95-4.95 in
None
IP67 conforming to IEC 60529
67
4.95 in
4.95 in
Not Applicable
80°
Not Applicable
112 ozf.in
208 ozf.in
Single End
NEMA 1 Nema type 250 || NEMA 2 Nema type 250 || NEMA 4 Nema type 250 || NEMA 12 Nema type 250 || NEMA 13 Nema type 250
1, 12, 13, 2, 4
2
Not Applicable
1
limit switch
cable pull switch
corrosion resistant gray paint
+/- 0.03 %
Not Applicable
severe duty mill
30 gn 9 ms IEC 60068-2-27
20 A Bussmann class CC KTK-R-20 non-time delay
CE Marked, CSA Certified, UL Listed
CW || from left
Maintained
Single Cable
20 A
17° cable operated stop switch
vertical approach
spring return without operating lever
10 gn 10-55 Hz)IEC 60068-2-6
2.31 in
1/2 in NPT
20 A
2.5 kV AC for 1 minute CE || 2.2 kV AC for 1 minute UL || 2.64 kV AC for 1 minute CSA
600 V 3)IEC 60947-1 || 600 V 3)UL 508 || 600 V 3)CSA C22.2 No 14
