Magnetic Coil, IEC, 480VAC, 60 Hz

SKU
Brand Square D
Categories
Description Replacement Coil, Coil Voltage 480V AC, NEMA Size Not Applicable, Compatible with Series LC1D80 Contactors, LC1D95 Contactors, TeSys Deca, Contactor Style IEC, Coil Power 220 VA, Frequency 60 Hz

Web Price

$69.49 / each

Qty

Product Details

Ambient Air Temperature For Operation -5-60 ÃÂ°C

Average Resistance 480 Ohm 20 ÃÂ°C

Coil Power 220 VA

Coil Technology without built-in suppressor module

Coil Voltage 480V AC

Coil Volts 480V AC

Compatible with Series LC1D80 Contactors, LC1D95 Contactors, TeSys Deca

Contactor Style IEC

Contactor Type IEC

Control Circuit Type AC 60 Hz

Control Circuit Voltage Limits drop-out 0.3 to 0.6 Uc 50/60 Hz 55 ÃÂ°C) || operational 0.8 to 1.1 Uc 50 Hz 55 ÃÂ°C) || operational 0.85 to 1.1 Uc 60 Hz 55 ÃÂ°C)

Country of Origin (subject to change) Czechia

Device Short Name LX1D6

For Use With LC1D40, 50, 65 and 80 Series Contactors

Frequency 60 Hz

Heat Dissipation 6-10 W 50/60 Hz

Hold-In Power Consumption In Va 22-22 VA 60 Hz 0.3 20 ÃÂ°C)

Hz_ 60

Inductance Of Closed Circuit 23 H

Inrush Power In Va 220-220 VA 60 Hz 0.75 20 ÃÂ°C)

Maximum Operating Rate 3600 cyc/h 60 ÃÂ°C

Mechanical Durability 10 Mcycles

NEMA Size Not Applicable
