Miniature Circuit Breaker, 40, 600VAC, 2 Pole, Bolt-On Mounting Style, EDB Series

SKU
Brand Square D
Categories
Description Miniature Circuit Breaker 600V 40A, Series EDB
graingerSKU: , mscSKU: , zoro_no: G0845525, mongo_id: 65bbe6393aaddbd5a90158ae

Web Price

$596.24 / each

Qty

Product Details

AC Voltage Rating 600VAC

Ambient Air Temperature For Operation 104ÃÂ°F (40ÃÂ°C)

Amps 40

Application HACR rated Applications

AWG Gauge AWG 12 to AWG 2/0 aluminium; AWG 14 to AWG 2/0 copper

Breaking Capacity 14 kA 600Y/347 V AC

Breaking Capacity Code D

Circuit Breaker Application HACR rated

Circuit Breaker Mounting Style Bolt-On

Country of Origin (subject to change) Mexico

Depth 4.05 in

Electrical Connection Lugs aluminium

Features Mercury Free

For Use With NF Panelboard

Frame Size D; E-Frame

Height 5.66 in

High Amp Trip Setting 1800 A

Holding Current 630 A

Interrupt Rating 14 kA at 600Y/347V AC

Line Rated Current 40 A

Local Signalling Trip indicator

Max. AIR Rating 14 kA

Max. Wire Size 2/0 AWG (Cu/Al)

Maximum Operating Voltage 600Y/347 V AC

Min. Wire Size 12 AWG (Al), 14 AWG (Cu)

Module Type E-Frame

Number of Poles 2

Package Quantity 1

Product Or Component Type Miniature circuit-breaker

Product Type Miniature Circuit Breaker 600V 40A

Protection Type Short-circuit; Overload

Series EDB

Standards cULus

Terminal Connection Lug

Tightening Torque 34.52 lbf.in (3.9 N.m) 0.00 to 0.01 inÃÂ² (2.5 to 6 mmÃÂ²) (AWG 14 to AWG 10); 49.56 lbf.in (5.6 N.m) 0.02 to 0.11 inÃÂ² (10 to 70 mmÃÂ²) (AWG 8 to AWG 2/0)

Trip Type Thermal Magnetic

Trip Unit Technology Thermal-magnetic

Width 1.96 in
