Home / Miniature Circuit Breaker, 80, 600VAC, 3 Pole, Bolt-On Mounting Style, EDB Series
Miniature Circuit Breaker, 80, 600VAC, 3 Pole, Bolt-On Mounting Style, EDB Series

Miniature Circuit Breaker, 80, 600VAC, 3 Pole, Bolt-On Mounting Style, EDB Series

  • Square D
  • Miniature Circuit Breaker 600V 80A, Series EDB
Web Price
$1,098.74 / each
Qty

Product Details

600VAC
104°F (40°C)
80
HACR rated Applications
AWG 12 to AWG 2/0 aluminium; AWG 14 to AWG 2/0 copper
14 kA 600Y/347 V AC
D
HACR rated
Bolt-On
Mexico
4.05 in
Lugs aluminium
Mercury Free
NF Panelboard
D; E-Frame
5.66 in
2300 A
1000 A
14 kA at 600Y/347V AC
80 A
Trip indicator
14 kA
2/0 AWG (Cu/Al)
600Y/347 V AC
12 AWG (Al), 14 AWG (Cu)
E-Frame
3
1
Circuit-breaker
Miniature Circuit Breaker 600V 80A
Overload; Short-circuit
EDB
cULus
Lug
34.52 lbf.in (3.9 N.m) 0.00 to 0.01 in² (2.5 to 6 mm²) (AWG 14 to AWG 10); 49.56 lbf.in (5.6 N.m) 0.02 to 0.11 in² (10 to 70 mm²) (AWG 8 to AWG 2/0)
Thermal Magnetic
Thermal-magnetic
2.94 in
