Molded Case Circuit Breaker, 200 A, 600V AC, 2 Pole, Plug In Panelboard Mounting Style, LA Series

SKU
Brand Square D
Categories
Description Molded Case Circuit Breaker, 200 A Amps, AC Voltage Rating 600V AC, Max. AIR Rating 42kA at 240V AC, For Use With I Line Panelboards, Series LA, High Amp Trip Setting 2,000 A, Low Amp Trip Setting 1,000 A, Circuit Breaker Type Standard, Number of Poles 2, DC Voltage Rating 250V DC, Terminal Connection Lug, Trip Type Thermal Magnetic, Phase Single, Instantaneous Trip Adjustable, Phase Connection AC, Frame Size 400A/LA, Circuit Breaker Mounting Style Plug In Panelboard, Height 11 in, Width 6 in
graingerSKU: 2GPA1, mscSKU: , zoro_no: G1884066, mongo_id: 65bbe8d822d7a989a991bc3b

Web Price

$4,763.74 / each

Qty

Product Details

AC Voltage Rating 600V AC

Amps 200 A

Application HACR rated Applications

Breaking Capacity Code A

Certifications CSA; UL Listed

Circuit Breaker Actuator Toggle

Circuit Breaker Application HACR rated

Circuit Breaker Mounting Style Plug In Panelboard

Circuit Breaker Type Standard

Country of Origin (subject to change) Mexico

DC Voltage Rating 250V DC

Depth 5.8 in

Electrical Connection Lugs, load; I-Line connection, line

Features Mercury Free; PVC Free

For Use With I Line Panelboards

Frame Size 400A/LA

Height 11 in

High Amp Trip Setting 2,000 A

Instantaneous Trip Adjustable

Low Amp Trip Setting 1,000 A

Magnetic Hold Current 1000 A

Magnetic Tripping Current 2000 A

Max. AIR Rating 42kA at 240V AC

Max. Wire Size 250 MCM (Al), 600 MCM (Cu)

Min. Wire Size 1 AWG (Al)

Mounting Plug In Panelboard

Mounting Mode I-Line

Number of Poles 2

Package Quantity 1

Phase Single

Phase Connection AC

Product Or Component Type Circuit breaker

Series LA

Standards CSA Certified, UL Listed

Terminal Connection Lug

Terminal Identifier AL400LA

Tightening Torque 115.06 lbf.in (13 N.m) 0.07 to 0.47 inÃÂ² (42 to 304 mmÃÂ²) (AWG 1 to 600 kcmil); 115.06 lbf.in (13 N.m) 0.07 to 0.20 inÃÂ² (42 to 127 mmÃÂ²) (AWG 1 to 250 kcmil)

Trip Type Thermal Magnetic

Trip Unit Technology Thermal-magnetic

Width 6 in

Wiring Configuration 2-wire
