Molded Case Circuit Breaker, 90 A, 240V AC, 3 Pole, Free Standing Mounting Style, QD Series

Molded Case Circuit Breaker, 90 A, 240V AC, 3 Pole, Free Standing Mounting Style, QD Series

  • Square D
  • Molded Case Circuit Breaker, 90 A Amps, AC Voltage Rating 240V AC, Max. AIR Rating 25kA at 240V AC, For Use With -, Series QD, High Amp Trip Setting 1,800 A, Low Amp Trip Setting 1,000 A, Circuit Breaker Type Standard, Number of Poles 3, DC Voltage Rating Not Rated, Terminal Connection Lug, Trip Type Thermal Magnetic, Phase Three, Instantaneous Trip Fixed, Phase Connection ABC, Frame Size 250A/QD, Circuit Breaker Mounting Style Free Standing, Height 6.47 in, Width 4.5 in, Depth 3.93 in

    graingerSKU: 2JXD9, mscSKU: , zoro_no: G2917975, mongo_id: 65bbe8b222d7a989a990d806

Web Price
$1,359.99 / each
Qty

Product Details

240V AC
104 to 158°F (40 to 70°C)
90 A
HACR rated Applications; Distribution
25 kA 120/208 V AC 50/60 Hz UL; 25 kA 240 V AC 50/60 Hz UL
D
Toggle
HACR rated
Free Standing
Standard
0.8
Operating handle
Mexico
Not Rated
3.93 in
Distribution
Lugs, load; Lugs, line
Mercury Free; PVC Free
250A/QD
6.47 in
1,800 A
Fixed
25 kA at 120/208/240V AC
1 trip indicator green)
1,000 A
1000 A
1800 A
25kA at 240V AC
104 Degrees F
300 MCM
1000 cycles loaded; 5000 cycles no load
4 AWG
Free Standing
Unit mount lug)
50/60 Hz
3
1
Three
ABC
0.87 in (22 mm)
UL; CSA; NOM
PowerPact Q
Circuit breaker
8 kV UL
240 V AC 50/60 Hz UL
QD
CSA, IEC, UL Listed
Lug
247.82 lbf.in (28 N.m) 0.04 to 0.23 in² (25 to 150 mm²) (AWG 4 to 300 kcmil)
Thermal Magnetic
Thermal-magnetic
Category A
4.5 in
