Female Flag Disconnect, 16 to 14 AWG, PK50

SKU
Brand Sta-Kon
Categories
Description Female Flag Disconnect, Contact Finish Tin, Contact Material Brass, Disconnect Style 90 Degree, Insulation Color Blue, Insulation Coverage Full Coverage, Insulation Material Nylon, Maximum Operating Temperature 221 Degrees F, Minimum Wire Size 16 AWG, Maximum Wire Size 14 AWG, Maximum Voltage 600 V, Tab Thickness 0.032 in, Tab Width 0.25 in, Terminal Type Socket, Termination Style Crimp, UL 94 Flammability Rating Not Rated, RoHS Compliant No, Seam Style Brazed, Standards UL E66716
graingerSKU: , mscSKU: , zoro_no: G2752215, mongo_id: 65bbe61c3aaddbd5a900a8e3

Web Price

$55.99 / each

Qty

Product Details

A (inches) 0.8

Application Tools WT145C, WT2000, WT112M, ERG4001, ERG4003

AWG-range 16-14

B (inches) 0.72

Barrel Inside Dia. 0.086 in

Barrel Inside Diameter 0.086 in

Barrel Size Long

Barrel Style Funnel Entry

Color Blue

Connection Material Tin-Plated Copper

Connection Orientation 90 Degrees Angled

Connection Type Crimp

Contact Finish Tin

Contact Material Brass

Country of Origin (subject to change) United States

Disconnect Style 90 Degree

Disconnect Type Female - 250 Series

Features Unique construction of the female disconnect offers long-term dependability.; Brazed seam serrated barrel provides maximum tensile strength.; Application Tools: WT145C, WT2000, WT112M, ERG4001; Alternate Package Qty: RB2577F

Finish Electro Tin-Plated

Flammability Rating UL 94 V-2

For Wire Size 14 AWG, 16 AWG

Insulation Full

Insulation Color Blue

Insulation Coverage Full Coverage

Insulation Material Nylon

Insulation Type Nylon

Material Brass

Material insulation PA

Max. Temp. 221 Degrees F

Max. Voltage 600 V

Maximum Insulation (inches) 0.2

Maximum Operating Temperature 221 Degrees F

Maximum Voltage 600 V

Maximum Wire Size 14 AWG

Minimum Wire Size 16 AWG

Overall Length 0.8 in

Package Quantity 50

Recommended Tool ERG4001

RoHS Compliant No

Seam Brazed

Seam Style Brazed

Special Features Brazed Seam Serrated Barrel Provides Maximum Tensile Strength, Unique Construction of the Female Disconnect offers Long-Term Dependability

Standards UL E66716

Tab Size 0.032 in x 0.250 in

Tab Thickness 0.032 in

Tab Width 0.25 in

Temperature Rating 105ÃÂ°C

Terminal Series RB

Terminal Type Socket

Terminal Types Female Socket

Termination Style Crimp

Type Nylon Insulated Open Top 90 Degree Flag Female Disconnect

UL 94 Flammability Rating Not Rated

Voltage Rating 600V
