Home / Inverter and Battery Charger, Polycarbonate And Aluminum Case, Sine Wave Form, 2000W Nominal Output

Inverter and Battery Charger, Polycarbonate And Aluminum Case, Sine Wave Form, 2000W Nominal Output

SKU
Brand Tripp Lite
Categories
Description Inverter and Battery Charger, Inverter Output Form Modified Sine Wave, DC Connection Input Terminals, Peak Output Power 4,000 W, Inverter Input Voltage 120V AC, Inverter Output Voltage 120V AC, Charger Input Voltage 120V AC, Charger Output Voltage 120V, Case Material Aluminum, Polycarbonate, Cooling Method Fan, Application Recreational Applications, Features Display Leds, Moisture-Resistant Construction Enables Vehicular Operation in High-Humidity Environments, Overtemperature Protection
graingerSKU: 19N909, mscSKU: , zoro_no: G4404181, mongo_id: 65bbe87122d7a989a98f5b01

Web Price

$1,729.99 / each

Qty

Product Details

Additional Information Extra Input: AC In

Application Recreational Applications

Automatic/Manual Automatic

Battery Charge 25A / 100A (user-selectable)

Battery Pack Accessory (Optional) 98-121 sealed lead acid battery (optional)

Case Material Polycarbonate And Aluminum

Certifications & Standards UL 458 (US & Canada)

Charger Depth 17.5 in

Charger DxWxH 17.5 in x 10.5 in x 8 in

Charger Height 8 in

Charger Input Current 20 A

Charger Input Voltage 120V AC

Charger Output Amps 100 A

Charger Output Current 100 A

Charger Output Voltage 120V

Charger Width 10.5 in

Continuous Output Capacity (Watts) 2000

Continuous Power Load 2000 W

Cooling Method Fan

Country of Origin (subject to change) China

DC Connection Terminal Posts

DC System Voltage (VDC) 12

Depth 10-1/2

Expandable Runtime Yes

Features Display Leds, Moisture-Resistant Construction Enables Vehicular Operation in High-Humidity Environments, Overtemperature Protection

Form Factors Supported Mounting slots enable secure placement of inverter on any horizontal surface (see manual for additional mounting information)

Frequency Compatibility 60 Hz

Front Panel LEDs 6 LEDs offer continuous status information on load (6 levels reported) and battery charge level (7 levels reported). See manual for sequences.

Height 8

High Voltage Transfer to Battery Power In AC auto mode, inverter/charger switches to battery mode as line voltage increases to 145V

Included Accessories Battery temperature sensor cable; conduit hanger

Includes Battery Temperature Sensor Cable, Conduit hanger

Input Connection Type DC INPUT: Set of 2 DC terminal posts. AC INPUT: hardwire. User supplies cabling. 0 gauge or larger (see manual). AC INPUT: hardwire

Input Voltage 12VDC

Inverter Depth 17.5 in

Inverter Height 8 in

Inverter Input Voltage 120V AC; 12V DC

Inverter Output Form Sine Wave

Inverter Output Voltage 120V AC

Inverter Width 10.5 in

Inveter Output Voltage 120V

Load Sensing Optional load-sense function enables automatic inverter shutoff and startup as connected equipment is powered off and on. Front panel load-sense potentiometer can be set to shutoff or turn on inverter power in response to loads of any level, up to 150 watts.

Low Voltage Transfer to Battery Power In AC auto mode, inverter/charger switches to battery mode as line voltage drops to 75V (user-adjustable to 85, 95, 105V - see manual)

LVC (Low Voltage Cut-Off) 10VDC +/-3%

Material of Construction Polycarbonate, Aluminum

Max. Input Current Full continuous load - 190 A at 12V DC; 38 A at 120V AC with full inverter and charger load

Maximum Frequency 60 Hz

Maximum Input Amps / Watts DC INPUT: Full continuous load - 190A at 12V DC. AC INPUT: 38 amps at 120V AC with full inverter and charger load (20A max charger-only / combined input load to support charger and AC output is automatically controllable to 66%-33%-0% based on AC output l

Nominal Input Voltage(s) Supported 120V AC

Nominal Output Power 2000W

Nominal Output Voltage(s) Supported 120V

Outlet Type Hardwire

Output Frequency 60 Hz

Output Frequency Regulation 60 Hz (+/- 0.3 Hz)

Output Receptacles Hardwire

Output Voltage 115VAC

Output Voltage Regulation LINE POWER (AC): Maintains 120V nominal sine wave output from line power source. INVERTER POWER (AC): Maintains PWM sine wave output voltage of 120V AC (+/-5%).

Overload Protection Includes 25A input breaker dedicated to the charging system

Package Contents PowerVerter MRV2012UL Inverter, Instruction Manual, Battery Temperature Sensor Cable, Conduit Hanger

Package Includes MRV2012UL Inverter/Charger;Instruction manual with warranty information;Battery Temperature Sensor cable;Conduit hanger

Package Quantity 1

Peak Output Capacity (Watts) 4000

Peak Output Power 4000W

Peak Power Load 4000 W

Plug/Connector Type Hardwired

Product Certifications UL 458

Product Color Black

Product Line PowerVerter

Product Name PowerVerter MRV2012UL Inverter

Product Type Power Inverter

Pure Sine Wave Output No

Receptacles Hardwired

Recommended Electrical Service DC INPUT: Requires 12V DC input source capable of delivering 190A for the required duration (when used at full continuous capacity - DC requirements increase during Over-Power and Double-Boost operation). For automotive applications, professional hardwire

Relative Humidity 0%-95% Non-Condensing

Standards RoHS, UL458

Switches 3-position on/off/remote switch enables simple on/off power control plus auto/remote setting that enables distant on/off control of the inverter system when used in conjunction with APSRM4 accessory (sold separately) in inverter mode. In AC uninterruptibl

Transfer Time (Line Power to Battery Mode) 16.6 ms (typical - compatible with many computers - verify transfer time compatibility of loads for UPS applications)

Unit Dimensions (hwd / in.) 8.000 x 10.500 x 17.500

Voltage Compatibility (VAC) 120

Voltage Compatibility (VDC) 12

Waveform Type Pulse-width Modulated Sine Wave

Width 17-1/2
