Home / Inverter, Polycarbonate Case, Sine Wave Form, 2000W Nominal Output, 120V Output Voltage, 2 Outlets

Inverter, Polycarbonate Case, Sine Wave Form, 2000W Nominal Output, 120V Output Voltage, 2 Outlets

SKU
Brand Tripp Lite
Categories
Description Inverter, Features Diagnostic LED, Frequency Control for Operating Stability, High-Efficiency Operation, Load Sense Function, RJ45 Port Allows Connection of APS/PowerVerter Remote Switch (APSRM4), Output Form Modified Sine Wave, Continuous Output Power 2,000 W, Peak Output Power 4,000 W, Number of Outlets 2, Input Voltage 12V DC, Output Voltage 120V AC, Output Frequency 60 Hz, Efficiency 90 Percent, Overall Depth 16 1/4 in, Overall Height 7 1/4 in, Overall Width 8 1/2 in
graingerSKU: 6LM57, mscSKU: , zoro_no: G1443111, mongo_id: 65bbe81b22d7a989a98d9073

Web Price

$992.49 / each

Qty

Product Details

Application Motors, Power Tools, Work Trucks

Case Material Polycarbonate

Certifications & Standards UL458 (USA, Canada)

Continuous Output Capacity (Watts) 2000

Continuous Output Power 2,000 W

Continuous Power Load 2000 W

Cooling Method Fan

Country of Origin (subject to change) China

DC Connection Input Terminals; Bolt Down Wiring Terminals

DC System Voltage (VDC) 12

Depth 16-1/4

Efficiency 90 %

Features Diagnostic LED, Frequency Control for Operating Stability, High-Efficiency Operation, Load Sense Function, RJ45 Port Allows Connection of APS/PowerVerter Remote Switch (APSRM4)

Form Factors Supported Mounting slots enable permanent placement of inverter on any horizontal surface (see manual for additional mounting information)

Frequency Compatibility 60 Hz

Front Panel LEDs Set of 6 LEDs offers continuous status information on load percentage (6 levels reported) and battery charge level (7 levels reported). See manual for sequences

Fused Yes

Height 7-1/4

Includes Set of High Current DC Input Terminals

Input Connection (2) Bolt-Down DC Wiring Terminals

Input Connection Type Set of 2 DC bolt-down wiring terminals

Input Cord Length Details User supplies cabling; 2/0 gauge or larger recommended

Input Current 200 A at 12V DC, 2.2 A at 12V DC

Input Voltage 12V DC

Inverter DxWxH 16 1/4 in x 8 1/2 in x 7 1/4 in

Inverter Input Voltage 12V DC

Inverter Output Form Sine Wave

Inverter Output Voltage 115V AC

Inveter Output Voltage 120V

Load Sensing Optional load sense function enables automatic inverter shutoff and startup as connected equipment is powered off and on. Front panel load sense potentiometer can be set to shutoff or turn on inverter power in response to loads of any level

Material of Construction Polycarbonate

Max. Input Current Full continuous load - 200 A at 12V DC; No load - 2.2 A at 12V DC

Maximum Frequency 60 Hz

Maximum Input Amps / Watts Full continuous load - 200A at 12V DC, No load - 2.2A at 12V DC

NEMA Rating NEMA 5-20

Nominal Output Power 2000W

Nominal Output Voltage(s) Supported 120V

Number of Outlets 2

Outlet Type Standard 3-Prong Outlet; NEMA 5-15/20R

Output Connection (2) NEMA 5-15R

Output Form Modified Sine Wave

Output Frequency 60 Hz

Output Frequency Regulation 60 Hz (+/- 0.3 Hz)

Output Receptacles (2) 5-15R

Output Voltage 120V AC

Output Voltage Regulation Maintains PWM sine wave output voltage of 120 V AC (+/-5%)

Overall Depth 16 1/4 in

Overall Height 7 1/4 in

Overall Width 8 1/2 in

Overload Protection Circuit breaker

Package Contents PowerVerter Plus 2000W Industrial-Strength Inverter with 2 Outlets, Instruction Manual

Package Includes PV2000FC Inverter;Instruction manual

Package Quantity 1

Peak Output Capacity (Watts) 4000

Peak Output Power 4000W

Peak Power Load 4000 W

Product Certifications UL 458

Product Color Black

Product Line PowerVerter

Product Name PowerVerter Plus 2000W Industrial-Strength Inverter with 2 Outlets

Product Type Power Inverter

Protection Type Overload Protection

Pure Sine Wave Output No

Real Power Rating 4,000 W

Receptacles 2 x NEMA 5-15R

Recommended Electrical Service Requires 12V DC input source capable of delivering 200A for the required duration (when used at full capacity). For automotive applications, professional hardwire installation with 400A battery system fusing is recommended

Relative Humidity 0%-95% Non-Condensing

Standards RoHS Compliant, UL 458

Switches 3-position on/off/remote switch enables simple on/off power control plus remote setting that enables distant on/off control of the inverter system when used in conjunction with optional APSRM4 accessory

Type of Indicator LED

Unit Dimensions (hwd / in.) 7.250 x 8.500 x 16.250

Voltage Compatibility (VDC) 12

Waveform Type Pulse-width Modulated Sine Wave

Width 8-1/2
