Name: UPS, SmartPro, NAFTA assembld, SMART3000NET
Brand: Tripp Lite
SKU: G5177125
Price: 2037.49 USD
Availability: OutOfStock

Home / UPS, SmartPro, NAFTA assembld, SMART3000NET

UPS, SmartPro, NAFTA assembld, SMART3000NET

SKU
Brand Tripp Lite
Categories
Description UPS,SmartPro,NAFTA assembld,SMART3000NET
graingerSKU: , mscSKU: , zoro_no: G5177125, mongo_id: 65bbe8729a749db822791970

Web Price

$2,037.49 / each

Product Details

AC Mode BTU / Hr. (Full Load) 82.4

AC Mode Efficiency Rating (100% Load) 0.99

Additional Information Line Mode: Sine wave line voltage 120V (-13% / +5%), Battery Mode: PWM sine wave output 120V +/-5%

Alarm Cancel Operation Power-fail alarm can be silenced using alarm-cancel switch; once silenced, alarm will re-sound to indicate low-battery status

Audible Alarm Audible alarm indicates power-failure, overload and low-battery conditions

Backup/Run Time (Full Load) 7 Minute

Backup/Run Time (Half Load) 20 Minute

Battery Mode Heat Dissipation (BTU/Hr) @ Full Load 1219.3

Battery Recharge Rate (Included Batteries) Less than 9 hours from 10% to 90%

Certifications & Standards UL1778 (USA), cUL (Canada), FCC Class A (emissions), NOM (Mexico)

Cold Start (Startup in Battery Mode During a Power Failure) Cold-start operation supported

Communications Cable 3 DB9 cables included

Communications Interface DB9 Serial; Contact closure

Cooling Method Fan

Country of Origin (subject to change) United States

DC System Voltage (VDC) 24

Depth 12.5

EMI / RFI AC Noise Suppression Yes

External Battery Pack Compatibility BP24V28-2U (limit 1); BP24V70-3U (multi-pack compatible)

Form Factor Tower

Frequency Compatibility 60 Hz

Height 17

High Voltage Transfer to Battery Power (Setpoint) 140

Input Current 22 A

Input Voltage 110 V AC

Installation Form Factors Supported with Included Accessories Tower

LED Indicators 5 LEDs indicate line power, battery power, overload, voltage regulation and battery low/replace status

Load Capacity 3000 VA/2400 W

Load Management Receptacles Three switchable single-outlet 5-15R load banks

Low Voltage Transfer to Battery Power (Setpoint) 87

Network Monitoring Port Description Supports detailed monitoring of UPS and site power conditions; contact closure communications via two additional DB9 ports (3 total)

Nominal Input Voltage(s) Supported 120V AC

Nominal Output Voltage(s) Supported 120V

Operating Temperature Range +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Output AC Waveform (AC Mode) Sine wave

Output AC Waveform (Battery Mode) PWM sine wave

Output Capacity (VA) 3000

Output Capacity (Watts) 2400

Output Circuit Breakers 15A branch rated (x2) - each breaker protects 4 outlets

Output Receptacles (4) 5-15R; (4) 5-15/20R

Output Voltage 120 V AC

Output Voltage Regulation (Battery Mode) +/- 5%

Output Voltage Regulation (Line Mode) -13% / +5%

Overvoltage Correction Input voltages between 127 and 140 are reduced by 12%

Package Contents SmartPro SM3000NAFTA 3000VA Tower UPS, SMART3000NET UPS System, PowerAlert Software and three 6 foot network cables, Warranty information, Instruction manual

Package Includes SMART3000NET UPS System;PowerAlert Software and three 6 foot network cables;Warranty information;Instruction manual

Package Quantity 1

Plug/Connector Type NEMA L5-30P

Power Factor 0.8

Primary Form Factor Tower

Primary UPS Depth (mm) 318

Primary UPS Height (mm) 432

Primary UPS Width (mm) 229

Product Line SmartPro

Product Name SmartPro SM3000NAFTA 3000VA Tower UPS

Product Type Line-interactive UPS

Rated input current (Maximum Load) 22A

Receptacle Detail 4 x NEMA 5-15R, 4 x NEMA 5-15/20R

Recommended Electrical Service 30A 120V

Relative Humidity 0 to 95%, non-condensing

Runtime Full Load (min.) 7 min. (2400w)

Runtime Half Load (min.) 23 min. (1200w)

Serial Port Yes

Severe Undervoltage Correction Input voltages between 87 and 94 are boosted by 22%

Software Included PowerAlert UPS Monitoring Software

Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius

Switches 2 Switches control off/on power status and alarm-cancel/self-test operation; set of 4 rear-panel switches control system enable and contact closure port inverter shutoff commands

Transfer Time 4 ms

Typical Battery Recharge Time 4 Hour

Undervoltage Correction Input voltages between 95 and 105 are boosted by 10%

UPS AC Suppression Joule Rating 480

UPS AC Suppression Response Time Instantaneous

UPS Housing Material PVC

UPS Input Connection Type L5-30P

UPS Input Cord Length (ft.) 8

UPS Power Module Dimensions (hwd, in.) 17 x 9 x 12.5

Voltage Regulation Description Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 87 to 140

Width 9
