Name: UPS System, 1.2 kW, 120 V AC
Brand: Tripp Lite
SKU: G301968938
Price: 513.74 USD
Availability: InStock

Home / UPS System, 1.2 kW, 120 V AC

UPS System, 1.2 kW, 120 V AC

SKU
Brand Tripp Lite
Categories
Description UPS System, Line Interactive, Power Rating 1.44 kVA, Wattage 1.2 kW, Input Voltage 120 V AC, Output Voltage 110V AC, 115V AC, 120V AC, Backup Time (Half/Full Load) 6 min/1.5 min, Mounting Tower, Outlet Type (6) UPS, (2) Surge, Number of Outlets 8, NEMA Receptacle Configuration 5-15R, Automatic Volts Regulation Yes, Transfer Time 6 msec, Width 140 mm, Depth 381 mm, Height 191 mm, Cord Length 5 ft, Display Type LCD, 50 Hz/60 Hz Hz, Input Current 12.0 A, 1 Phase, Ports RS232, USB (HID Enabled)
graingerSKU: 783X65, mscSKU: , zoro_no: G301968938, mongo_id: 65bbe7ee9a749db822766766

Web Price

$513.74 / each

Qty

Product Details

AC Mode BTU / Hr. (Full Load) 175

AC Mode Efficiency Rating (100% Load) >95%

Audible Alarm UPS remains silent in battery backup mode; Alarm sounds only to report low-battery, fault, overload and replace-battery conditions

Audible Noise Less than 50db (front side, 1m)

Automatic Volts Regulation Yes

Backup Time (Half/Full Load) 6 min/1.5 min

Battery Access Battery access door

Battery Recharge Rate (Included Batteries) 8 hours (10% to 90%)

Battery Replacement Description Replaceable internal batteries (see manual)

Battery Type Valve Regulated Lead Acid (VRLA)

Cold Start (Startup in Battery Mode During a Power Failure) Cold-start operation supported

Communications Cable USB and Serial interface cables included

Communications Interface DB9 Serial; USB (HID enabled)

Cooling Method Fan

Cord Length 5 ft

Country of Origin (subject to change) Viet Nam

DC System Voltage (VDC) 12

Depth 381 mm

Display Type LCD

EMI / RFI AC Noise Suppression Yes

Expandable Runtime No

Frequency Compatibility 50 / 60 Hz

Front Panel LCD Display Touchscreen LCD reports input voltage, output voltage, load percentage, battery charge percentage and overload status

Full Load Runtime (min.) 1.5 min. (1200w)

Half Load Runtime (min.) 6 min. (600w)

Height 191 mm

High Availability UPS Features Battery Independent Restart

High Voltage Transfer to Battery Power (Setpoint) 145

Hot-Swap PDU options PDUB15 (2U / 8 5-15R outlets)

Hz_ 50 Hz/60 Hz

Includes DB9 Cable, USB Cable

Individually Controllable Load Banks No

Input Circuit Breakers 15A

Input Current 12.0 A

Input Phase Single-Phase

Input Voltage 120 V AC

Installation Form Factors Supported with Included Accessories Tower

Low Voltage Transfer to Battery Power (Setpoint) 89

Mounting Tower

NEMA Receptacle Configuration 5-15R

Nominal Input Voltage(s) Supported 120V AC

Nominal Output Voltage(s) Supported 110V; 115V; 120V

Nominal Voltage Details 120v nominal output in battery mode

Number of Outlets 8

Operating Elevation (ft.) Up to 10,000ft

Operating Temperature Range +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius

Outlet Type (6) UPS, (2) Surge

Output AC Waveform (AC Mode) Pure sine wave

Output AC Waveform (Battery Mode) PWM sine wave

Output Capacity (VA) 1440

Output Capacity (Watts) 1200

Output kVA Capacity (kVA) 1.44

Output kW Capacity (kW) 1.2

Output Receptacles (8) 5-15R

Output Volt Amp Capacity (VA) 1440

Output Voltage 110V AC, 120V AC

Output Voltage Regulation (Battery Mode) 120V (ÃÂ±10%)

Output Voltage Regulation (Line Mode) 120V (+6%/-12%)

Output Watt Capacity (Watts) 1200

Overvoltage Correction Input voltages between 128 and 149 are reduced by 15%

Package Includes SMART1500TSU 1440VA 1200W 120V Line-Interactive UPS with 8 Outlets;USB cable;DB9 cable;Owner's manual

Package Quantity 1

Phase 1

Ports RS232, USB (HID Enabled)

Power Factor 0.83

Power Rating 1.44 kVA

PowerAlert Software For local monitoring via the UPSÃ¢ÂÂ¢s built-in communication ports, download PowerAlert Local software at http://www.tripplite.com/poweralert

Primary Form Factor Desktop

Primary UPS Depth (mm) 381

Primary UPS Height (mm) 191

Primary UPS Width (mm) 140

Product Certifications RETIE (Colombia); CSA (Canada); NOM (Mexico); UL 1778

Product Compliance FCC Part 15 Class A (USA)

Rated input current (Maximum Load) 12A

Recommended Electrical Service 15A 120V

Relative Humidity 0 to 90%, non-condensing

Runtime Full Load (min.) 1.5 min. (1200W)

Runtime Half Load (min.) 6 min. (600W)

Special Features Advanced Communications Ports Allow for Automatic Saves and Shutdowns, Automatic Voltage Regulation Corrects Low- and High-Voltage Conditions, Compact Housing Compatible with Easy Desktop Installation, Home Friendly Silent Alarm and LCD Touchscreen, Pure Sine Wave Output

Standards 47 CFR FCC Part 15 Subpart B, CAN/CSA-C22.2 NO. 107.3-14, CSA, FCC Part 15 Category A (EMI), FCC Part 68 Approved, ICES-003:2017, NOM, UL1778

Storage Temperature Range +5 to +113 degrees Fahrenheit / -15 to +45 degrees Celsius

Switches Power off/on switch

Transfer Time 6 msec

Undervoltage Correction Input voltages between 89 and 108 are boosted by 18%

UPS AC Suppression Joule Rating 316

UPS AC Suppression Response Time Instantaneous

UPS Applications Home/Office Desktop; Audio/Video; High-End Desktop/Small Network; Retail/Point of Sale; Hospitality

UPS Certification Details UL1778: 2014 5th EDITION; CAN/CSA-C22.2 NO. 107.3:2014 3rd EDITION; FCC CLASS A; FCC Part 68 Approved (#5WSWP01B005); Industry Canada Approved (#3449A-005, REN0.1B); RETIE (Colombia)

UPS Certifications Meets FCC Part 15 Category A (EMI); Tested to CSA (Canada); Tested to NOM (Mexico); Tested to UL1778 (USA)

UPS Dataline Suppression 1 line TEL/DSL or Ethernet

UPS Housing Material ABS

UPS Input Connection Type 5-15P

UPS Input Cord Length (ft.) 5

UPS Output Receptacles (Surge Suppression Only) 6 UPS outlets, 2 surge-only outlets

UPS Power Module Dimensions (hwd, in.) 7.5 x 5.5 x 15

UPS Type Line Interactive

Voltage Regulation Description Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 89 to 145

WatchDog Compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications

Wattage 1.2 kW

Width 140 mm
