Motor, 1/2 HP, 1075 rpm, 48Y, 208-230/460V

SKU
Brand U.S. Motors
Categories
Description Condenser Fan Motor, Single Phase, Motor Design Permanent Split Capacitor, 1/2 HP, Nameplate RPM 1,075, No. of Speeds 1, Voltage 208-230/460V AC, Full Load Amps 2 .8/1 .4 A, 48Y Frame, OEM Replacement Brand Amana, Usable @ 208V Yes, Usable @ 200V No, 60 Hz, Motor Service Factor 1, Motor Thermal Protection Auto, Ins. Class B, Max. Ambient Temp. 60 Degrees C, Duty Cycle Continuous, Motor Shaft Rotation CW/CCW, Motor Enclosure Design Totally Enclosed Air-Over, Motor Mounting Type Ring/Stud

Web Price

$396.24 / each

Qty

Product Details

Body Dia. 5.7 in

Capacitor Required Yes

Country of Origin (subject to change) Mexico

Duty Continuous

Duty Cycle Continuous

Frame 48Y

Full Load Amps 2 .8/1 .4 A

HP_ 1/2

Hz_ 60

Ins. Class B

Length Less Shaft 6 15/16 in

Max. Ambient Temp. 60 Degrees C

Motor Application HVAC/R

Motor Bearings Ball

Motor Design Permanent Split Capacitor

Motor Enclosure Design Totally Enclosed Air-Over

Motor Mounting Type Ring/Stud

Motor Service Factor 1

Motor Shaft Design Flat

Motor Shaft Rotation CW/CCW

Motor Sub Application Condenser Fan

Motor Thermal Protection Auto

Nameplate RPM 1,075

No. of Speeds 1

Number of Shafts 1

OEM Replacement Brand Amana

Overall Length 11 7/8 in

Package Quantity 1

Phase Single

RPM Range 1,001-1,100

Shaft Dia. 1/2 in

Shaft Length 5 in

Standards CSA (156060), UL (E22922)

Usable @ 200V No

Usable @ 208V Yes

Voltage 208-230/460V AC

Voltage Compatibility 208-220/440V AC, 208-230/460V AC, 208-230V AC, 208-240V AC, 208V AC, 220-230/460V AC, 220/460V AC, 230/460V AC, 230V AC, 240V AC, 460V AC

Weight 20 lb
