Male Disconnect, Blue, 16-14AWG, PK10

SKU
Brand Velvac
Categories
Description Male Disconnect, Contact Finish Tin, Contact Material Copper, Disconnect Style Tab, Insulation Color Blue, Insulation Coverage Full Coverage, Insulation Material Nylon, Maximum Operating Temperature 194 Degrees F, Minimum Wire Size 16 AWG, Maximum Wire Size 14 AWG, Maximum Voltage 600 V, Tab Thickness 0.032 in, Tab Width 0.25 in, Terminal Type Tab, Termination Style Crimp, RoHS Compliant Yes, Seam Style Brazed, Standards UL Listed, Barrel Inside Diameter 0.097 in, Barrel Style Funnel Entry
graingerSKU: 21DH11, mscSKU: , zoro_no: G5377477, mongo_id: 65bbe8979a749db82279eb34

Web Price

$11.74 / each

Qty

Product Details

Barrel Inside Dia. 0.097 in

Barrel Inside Diameter 0.097 in

Barrel Style Funnel Entry

Connection Material Copper

Connection Type Crimp

Contact Finish Tin

Contact Material Copper

Country of Origin (subject to change) United States

Disconnect Style Tab

For Wire Size 14 AWG, 16 AWG

Insulation Full

Insulation Color Blue

Insulation Coverage Full Coverage

Insulation Material Nylon

Insulation Type Heat Shrink

Max. Temp. 221 Degrees F

Max. Voltage 600 V

Maximum Operating Temperature 194 Degrees F

Maximum Voltage 600 V

Maximum Wire Size 14 AWG

Minimum Operating Temperature -40 Degrees F

Minimum Wire Size 16 AWG

Overall Length 1.35 in

Package Quantity 10

RoHS Compliant Yes

Seam Brazed

Seam Style Brazed

Special Features Crimp and Seal Style Terminals are the Most Comprehensive and Highest Quality Line of Crimp and Seal Heat Shrinkable Connectors in Todays Market, It Has Seamless Tubular Splices Which Ensure Mechanical and Electrical Integrity Under Severe Conditions, The Brazed Seam Terminals will Not Split Open Under the Most Extreme Installation and Operating Conditions, The Heat Shrink Tubing Which is 3:1 Dual Wall Tubing With Adhesive Lining Provides a Waterproof Seal With Durable Abrasion Resistance

Standards UL Listed

Tab Size 0.032 in x 0.250 in

Tab Thickness 0.032 in

Tab Width 0.25 in

Terminal Type Tab

Terminal Types Male Tab

Termination Style Crimp

Wire Range 16 to 14 AWG

Wire Size Range 16 AWG - 14 AWG
