Home / 1/2" X 1/2" Press Low Lead Bronze Spring Check Valve

1/2" X 1/2" Press Low Lead Bronze Spring Check Valve

SKU
Brand Viega
Categories
Description Item - Check Valves Check Valve, Flow Design Single, Mechanism and Body Design Inline Spring, Body Material - Valves Bronze, Pipe or Tube Size 1/2 in, Connection Type Press x Press, Cracking Pressure 0.5 psi, Mounting Orientation Horizontal, Vertical, Seal Material EPDM, Max. Temp. - Valves 200 Degrees F, Min. Temp. - Valves 0 Degrees F, Max. Water Pressure - Valves 200 psi @ 200 Degrees F, Max. Steam Pressure - Valves Not Rated, Spring Material Stainless Steel, Full Flow - Valves No
graingerSKU: 5ULX8, mscSKU: , zoro_no: G3147155, mongo_id: 65bbe7859a749db822740204

Web Price

$42.49 / each

Qty

Product Details

Application - Valves General Purpose

Body Material Bronze

Body Material - Valves Bronze

Compliance ABS: America Bureau of Shipping, CRN 0A14541.5 A/B/C, CSA MSE-13, FM Class 1920, IAPMO PS117, ICC-ES PMG-1037, NSF 61, NSF 372, ULC/ORD 213

Connection P x P

Connection Type Press x Press

Connection Type - Check Valves Press x Press

Country of Origin (subject to change) Germany

Cracking Pressure 0.5 psi

Cracking Pressure - Check Valves 0.500 psi

Features Smart Connect

Flow Design Single

Full Flow - Valves No

Item - Check Valves Check Valve

Length 1

Material of Construction Bronze

Max. Pressure 200 psi

Max. Steam Pressure - Valves Not Rated

Max. Temp. - Valves 200 Degrees F

Max. Water Pressure 200 psi

Max. Water Pressure - Valves 200 psi @ 200 Degrees F

Mechanism and Body Design Inline Spring

Min. Temp. - Valves 0 Degrees F

Mounting Orientation Horizontal, Vertical

Mounting Orientation - Check Valves Horizontal, Vertical

Package Quantity 1

Pipe or Tube Size 1/2 in

Pipe or Tube Size - Check Valves 1/2 in

Pipe Size 1/2

Seal Material EPDM

Seal Material - Check Valves EPDM

Size 1/2

Spring Material Stainless Steel

Spring Material - Check Valves Stainless Steel

Standards CRN: Canadian Registration Number, CSA International: Canadian Standards Association, IAPMO: Uniform Plumbing Code, ICC: International Plumbing Code, NSF/ANSI 61: Drinking Water System Comp, ABS: America Bureau of Shipping, CRN 0A14541.5 A/B/C, NSF 61, NSF 372

Sub-Category Bronze

Temp. Range 0 Degrees F to 250 Degrees F

Valve Body Material Bronze
