Viega MegaPressG adapter, 1" x 1/2"

SKU
Brand Viega
Categories
Description Adapter, Application Air, Fuel, Natural Gas, Fitting Side A Connection Type Press-Fit, Fitting Side B Connection Type FNPT, Fitting Material Carbon Steel, Fitting Side A Pipe Size 1 in, Fitting Side B Pipe Size 1/2 in, O-Ring Material HNBR, Specific Fitting Shape Straight Adapter, Finish/Coating Zinc Nickel-Plated, Overall Length 2 29/32 in, Maximum Operating Pressure 125 psi, Maximum Operating Temperature 180 Degrees F
graingerSKU: 31XK08, mscSKU: , zoro_no: G6202612, mongo_id: 65bbe94a22d7a989a9947adc

Web Price

$42.86 / each

Qty

Product Details

Application Air, Fuel, Natural Gas

Basic Pipe Fitting Material Metal

Basic Pipe Fitting Shape Adapter

Compliance ABS: American Bureau of Shipping, CRN: 0A14541.5 A/B, CSA ANSI LC4/CSA 6.32, CSA B149.1, IAPMO ANSI LC4/CSA 6.32, ICC-ES PMG-1036

Connection Type Press-Fit x FNPT

Country of Origin (subject to change) Germany

End Connection Type Press, Threaded

Finish/Coating Zinc Nickel-Plated

Fitting Body Material Zinc Nickel-Plated Carbon Steel

Fitting Connection Type Press x Female Pipe Thread

Fitting Material Carbon Steel

Fitting Pipe Size 1/2 in, 1 in

Fitting Shape Adapter

Fitting Side A Connection Type Press-Fit

Fitting Side A Pipe Size 1 in

Fitting Side B Connection Type FNPT

Fitting Side B Pipe Size 1/2 in

Max. Pressure 125 psi

Maximum Operating Pressure 125 psi

Maximum Operating Temperature 180 Degrees F

Minimum Operating Temperature 40 Degrees F

O-Ring Material HNBR

Overall Length 2 29/32 in

Package Quantity 1

Pipe Fitting Connection Type Press x Female Pipe Thread

Pipe Size 1 in x 1/2 in

Pipe Size (Fittings) 1 x 1/2

Pipe Size - Pipe Fitting 1 in x 1/2 in

Resistance Properties Chemical-Resistant, Heat-Resistant, Oil-Resistant

Specific Fitting Shape Straight Adapter

Specific Pipe Fitting Shape Adapter

Standards ABS Type Approval, ANSI LC4/CSA 6.32, CRN 0A14541.5 A/B, CSA ANSI LC4/CSA 6.32, CSA B149.1, IAPMO, IAPMO ANSI LC4/CSA 6.32, ICC, ICC-ES PMG-1036, IFGC, NFPA 54, NFPA 58

Stop and Shape Straight Adapter

Temp. Range -40 Degrees to 180 Degrees F

Tube Fitting Material Carbon Steel

Tube Size 1 x 1/2
