Indexable Face Mill, VSM11 Series, High Speed Steel, 11.32mm Depth of Cut

SKU
Brand Widia
Categories
Description Indexable Profiling End Mill, Depth of Cut 11.32mm, Overall Length 63.00mm, ANSI Code VSM11D125Z011S040XD11, Compatible Hardware Coolant Screw Assembly M20, Insert Screw M2.5x0.45 x 5.9 T8, Torx Wrench TX8, Coolant Fed Coolant Through, Cutting Application Face Milling, Helical Milling, Pocketing, Ramping: Blank, Side and Face Milling, Side/Shoulder Milling: Square End, Slotting: Square End
graingerSKU: 274FR5, mscSKU: , zoro_no: G3799465, mongo_id: 65bbe8819a749db822796ca3

Web Price

$1,458.74 / each

Qty

Product Details

ANSI Code VSM11D125Z011S040XD11

Arbor Dia. 40.00mm

Compatible Hardware Coolant Screw Assembly M20, Insert Screw M2.5x0.45 x 5.9 T8, Torx Wrench TX8

Coolant Fed Coolant Through

Country of Origin (subject to change) Bulgaria

Cutting Application Face Milling, Helical Milling, Pocketing, Ramping: Blank, Side and Face Milling, Side/Shoulder Milling: Square End, Slotting: Square End

Cutting Direction Right Hand

Depth of Cut 11.32mm

Features Effective Internal Coolant Feature, Increased Ramping Capability, Precisely Reaching the Cutting Edge, Superior Wall and Surface Finish Capabilities, True 90 Degrees Capability

Hub Outside Dia. 80.00mm

Insert Holding Type Screw

Insert Shape 75 Degrees Parallelogram

Insert Size 110408

Insert Style XD.T PD R

ISO Number VSM11D125Z011S040XD11

Material - Machining High Speed Steel

Max. Speed 12,100 RPM

Overall Length 63.00mm

Package Quantity 1

Rake -2.767 Degrees Radial, 12 Degrees Axial

Series VSM11
